Deploying LiveKit for Matrix Video Conferencing

So, you're looking to add real-time audio and video to your Matrix setup? LiveKit is an excellent open-source WebRTC project that can power features like Element Call directly from your own infrastructure. This guide will walk you through deploying a self-hosted LiveKit server using Docker, keeping things consistent with how we've handled Continuwuity and Synapse deployments.

Here, we'll cover deploying LiveKit using Docker for consistency with the other guides.

How it Works: Element Call & LiveKit

Before diving into deployment, let's quickly visualise how a client like Element Call uses your self-hosted LiveKit server. The key is the Matrix .well-known discovery mechanism:

graph TD
    Client["User Client"] --> WK["Fetch .well-known<br>from Matrix Server"]
    WK --> WSS["Connect Signaling (wss://livekit.your.domain)"];
    WSS --> Proxy["Reverse Proxy<br>TCP 443<br>(Nginx/Caddy)"];
    Client -.-> Indirect["<b>Fallback:</b><br>Indirect Media"];
    Client -. "<b>Preferred:</b><br>Direct UDP<br>(50000-50100)" .-> Internet["Peers on Internet"];
    Indirect -. TURN via TLS .-> Proxy;
    Proxy --> LiveKit["LiveKit Server<br>(SFU/TURN Controller)"];
    Indirect -. TURN via UDP .-> LiveKit;
    LiveKit --> Relay["Relays Media<br>(TURN)"];
    Relay --> Internet;

Discovery: Element Call reads your main Matrix domain's .well-known file to find the livekit_service_url.
Signaling: It connects via Secure WebSockets (wss://) to your LiveKit domain, usually through your reverse proxy (Nginx/Caddy) on port 443.
Media: For the actual audio/video streams (WebRTC), clients try to connect directly via UDP (ports 50000-50100). If firewalls block this, they use the integrated TURN service (UDP 3478 or TCP 443 via the proxy) as a fallback relay. LiveKit includes TURN, so no separate TURN server is needed.

Deployment Options

When deploying LiveKit with Docker, you've basically got two main routes, mostly depending on how you want to handle incoming connections and TLS (HTTPS):

Caddy Deployment (Official Generator): Uses the official LiveKit configuration generator. This bundles Caddy, which neatly handles automatic HTTPS and reverse proxying. It's often simpler if you don't already have a reverse proxy setup or prefer Caddy.
Manual Docker + Nginx Deployment: A more manual setup using Docker Compose and configuring Nginx as the reverse proxy. This gives you more control and is probably the way to go if you already use Nginx configuration.

Choose the guide that makes the most sense for your current server setup and comfort level. Either way, you'll need the prerequisites covered next.

Prerequisites

Before we get started with the specific Caddy or Nginx steps, let's make sure you have the basics in place:

A domain name (e.g. livekit.your.domain) that you control. You'll point this at your LiveKit server.
Access to manage DNS records for this domain. We need this to point the domain to your server's IP.
A Virtual Machine (VM) or server with Docker and Docker Compose installed. Nginx is also required for the Nginx guide.

Firewall Configuration

LiveKit requires specific network ports to be open on your server's firewall.

Port(s)	Protocol	Direction	Required By	Notes
80	TCP	Inbound	Caddy / Nginx	HTTP access for Let's Encrypt TLS certificate validation or HTTP redirect.
443	TCP	Inbound	Caddy / Nginx / LiveKit	Primary HTTPS, WSS, WebRTC/TCP fallback, TURN/TLS fallback.
3478	UDP	Inbound	LiveKit (TURN Service)	Primary TURN/UDP relay protocol for clients behind restrictive firewalls.
50000-50100	UDP	Inbound	LiveKit (Media)	Preferred range for direct WebRTC media streams (SRTP). See warning below.

Tip

Ensure these ports are allowed through both the server's host firewall (e.g. ufw, firewalld) and any upstream network firewalls (cloud provider security groups, router port forwarding).

Docker Performance with Large UDP Port Ranges

Using very large UDP port ranges (like the old default of 10,000+ ports) can cause significant delays when starting Docker containers. This is because Docker creates individual firewall (iptables) rules for each port in the range when using default networking.

To avoid this, I recommend both of the following: 1. Use a smaller port range: Configure LiveKit (in livekit.yaml) to use a smaller range (e.g. 100-200 ports like 50000-50100) and open only those ports in your firewall. This is the recommended approach for most setups. 2. Use Host Networking: Configure the LiveKit container to use network_mode: host in Docker Compose, which bypasses Docker's network isolation and (some of) the iptables issue.

See the specific Caddy or Nginx deployment guides for details.

Refer to the LiveKit firewall documentation for more general details.

DNS Configuration

Simple but crucial: create DNS A records (and AAAA if you use IPv6) for your LiveKit domain (e.g. livekit.your.domain). These records must point to the public IP address of the server where LiveKit will run.

Your reverse proxy (Caddy or Nginx) needs this record to be resolvable from the public internet to successfully obtain or use TLS certificates. You can check this using host livekit.your.domain. If this isn't set up correctly, Caddy won't get certificates, and Nginx won't work properly with HTTPS.

Matrix Integration (Element Call)

Okay, so LiveKit is running and accessible at https://livekit.your.domain. Now you need to tell Matrix clients (like Element Call) how to discover and use your self-hosted instance. This is done via the .well-known configuration file on your main Matrix domain.

Modify the file served at https://your.matrix.domain/.well-known/matrix/client to include the org.matrix.msc4143.rtc_foci key. Make sure to replace your.matrix.domain and livekit.your.domain with your actual domains:

.well-known/matrix/client

{
  "m.homeserver": {
    "base_url": "https://your.matrix.domain"
  },
  // ... other keys like m.identity_server might be present ...
  "org.matrix.msc4143.rtc_foci": [
    {
      "type": "livekit",
      "livekit_service_url": "https://livekit.your.domain" // Use your LiveKit domain here
    }
  ]
  // ... potentially other keys ...
}

CORS Headers Required for .well-known

Ensure your web server/reverse proxy serving the .well-known/matrix/client file (which is usually the one for your main Matrix domain, not the LiveKit domain) has the correct CORS headers (like Access-Control-Allow-Origin: *) to allow clients from any origin to fetch it. Without proper CORS headers, Element Call (running in a browser) won't be allowed to read this configuration and will fail to initiate calls using your LiveKit server.

Upgrading

Keeping LiveKit up-to-date is straightforward with Docker Compose. The recommended approach for most self-hosters is to use the :latest tag, which simplifies updates.

Pull the Latest Image: Navigate to your LiveKit configuration directory (e.g. /opt/livekit/) and pull the newest image versions:
Bash
```
cd /opt/livekit/
docker compose pull
```
This command pulls the latest versions for all services defined in your docker-compose.yaml, including livekit/livekit-server:latest and potentially redis or caddy. 2. Restart Services: Apply the new images by recreating the containers:
Bash
```
docker compose up -d
```

If you prefer to pin to specific versions (e.g. livekit/livekit-server:v1.5.3), you would first edit the image: line in your /opt/livekit/docker-compose.yaml file to specify the desired version tag, and then run the docker compose pull && docker compose up -d commands as above.

Troubleshooting Tips

LiveKit has an official tool at https://livekit.io/connection-test that can help narrow down issues - enter your wss URL (e.g. wss://livekit.your.domain) and run. It will attempt various connection methods and report success or failure, which can help narrow down the cause of the problem.

Refer to the official LiveKit troubleshooting guide for more details.
